Single Axle Galvanized Steel Boat Trailer 680 Cm 356 Kgs For Fiberglass Boats

Certification
Good quality Small Rib Boat for sales
I'm Online Chat Now

Single Axle Galvanized Steel Boat Trailer 680 Cm 356 Kgs For Fiberglass Boats

China Single Axle Galvanized Steel Boat Trailer 680 Cm 356 Kgs For Fiberglass Boats supplier
Single Axle Galvanized Steel Boat Trailer 680 Cm 356 Kgs For Fiberglass Boats supplier Single Axle Galvanized Steel Boat Trailer 680 Cm 356 Kgs For Fiberglass Boats supplier

Large Image :  Single Axle Galvanized Steel Boat Trailer 680 Cm 356 Kgs For Fiberglass Boats

Product Details:

Place of Origin: CHINA
Brand Name: CMEC
Certification: CE
Model Number: TR680

Payment & Shipping Terms:

Minimum Order Quantity: 1
Price: negotiate
Packaging Details: carton , weaving bag
Delivery Time: 7 days for one sample
Payment Terms: T/T, L/C, Western Union
Supply Ability: 100 pcs per Month
Contact Now
Detailed Product Description
Materials: Galvanized Steel Axle: Single
Payload: 1600kgs Net Weight: 356kgs
Length: 680cm Certificate: CE
High Light:

Heavy Duty Boat Trailers

,

Foldable Boat Trailer

680cm long big Galvanized steel boat trailer TR680 for rib boats and fiberglass boats in all sizes with big payload



Our boat trailers are made of galvanized steel for RIB and fiberglass boats



Generally, a boat trailer is designed to tow a boat on land. It consists of jack, hand winch, hitch ball, coupler and trailer.



In the most basic terms , a boat trailer is a wheeled frame made to transport a boat across land by towing it behind a any vehicle . The frame could be basic for all boats .



The boat trailer is linked to a car or truck by way of a locking coupler placed at the end of the tow bar .



Before towing a boat , make sure that the winch and coupler both have been locked and the boat is now secure



Features :



 A: Galvanized steel
 B:For  rib and fiberglass boats
 C: All sizes for the rib boats
 D: Big payload





Basic data : Customized size can be accepted .





MODEL LENGTH(MM) WIDTH(MM) TYRE AXLE PAYLOAD(KGS)

NET WEIGHT

(KG)

TR330 3480 1570 155R12 One axle 500 196
TR350 3680 1570 155R12 One axle 500 199
TR390 3850 1570 155R12 One axle 600 202
TR430 4330 1570 155R12 One axle 700 216
TR480 4580 1730 155R12 One axle 700 223
TR520 4880 1730 155R12 One axle 1050 226
TR550 5180 1730 155R12 One axle 1050 230
TR580 5900 2070 175/180R13 One axle 1250 325
TR600 6090 2070 175/180R13 One axle 1350 339
TR680 6930 2180 185R14 One axle 1600 356
TR700 7100 2180 185R14 One axle 2000 366
TR830 8500 2690 185R14 Two axles 3400 585
TR960 9550 2690 185R14 Two axles 4500 612



 Both uniaxial brake and biaxial brake are available .
